10 lb x 0.001 lb
Platform: 9.8" x 9.8"
High Pressure Washdown IP69K
Price: Lowest Price in Cart
Ground S&H: $50.00
Advanced IP68/IP69K Washdown Bench Scale Standard Features:
|
Ohaus Defender 6000 Series - Extreme Washdown Bench Scales | |||
---|---|---|---|
Model | NTEP Cap x Read | Indicator | Pan Size |
i-D61XWE5K1S6 | 10 lb x 0.002 lb 5 kg x 1 g |
Stainless Steel | 9.8" x 9.8" |
i-D61XWE12K1R6 | 25 lb x 0.005 lb 12.5 kg x 5 g |
Stainless Steel | 11.8" x 11.8" |
i-D61XWE25K1R6 | 50 lb x 0.01 lb 25 kg x 5 g |
Stainless Steel | 11.8" x 11.8" |
i-D61XWE50K1L7 | 100 lb x 0.02 lb 50 kg x 10 g |
Stainless Steel | 19.7" x 15.7" |
i-D61XWE150K1L7 | 300 lb x 0.1 lb 150 kg x 50 g |
Stainless Steel | 19.7" x 15.7" |
i-D61PW5K1S6 | 10 lb x 0.002 lb 5 kg x 1 g |
Polycarbonate Plastic | 9.8" x 9.8" |
i-D61PW12K1R6 | 25 lb x 0.005 lb 12.5 kg x 5 g |
Polycarbonate Plastic | 11.8" x 11.8" |
i-D61PW25K1R6 | 50 lb x 0.01 lb 25 kg x 5 g |
Polycarbonate Plastic | 11.8" x 11.8" |
i-D61PW50K1L7 | 100 lb x 0.02 lb 50 kg x 10 g |
Polycarbonate Plastic | 19.7" x 15.7" |
i-D61PW150K1L7 | 300 lb x 0.1 lb 150 kg x 50 g |
Polycarbonate Plastic | 19.7" x 15.7" |
Defender 6000 i-D61XWE5K1S6 Specifications | |
---|---|
Capacity x Readability (lb) | 10 lb x 0.001 lb |
Capacity x Readability (kg) | 5 kg x 0.5 g |
Max. Displayed Resolution | 1:10,000 |
Capacity x Readability (NTEP lb) |
10 lb x 0.002 lb |
Capacity x Readability (NTEP kg) |
5 kg x 1 g |
Max Certified Resolution | 1:5,000 |
Linearity/Repeatability | ± 2d |
Indicator | i-DT61XWE |
Column | 10.2 in / 260 mm 316 stainless steel |
Base Construction | 316 stainless steel top and bottom frame, hermetically sealed IP68/IP69K stainless steel loadcell |
Safe Overload Capacity | 150% of maximum capacity |
Stabilization Time | Within 1 second |
Operating Temp. Range | 14 °F to 104 °F / -10 °C to 40 °C |
Scale Dimensions |
9.8 x 9.8 x 4.2 x - x 20.4 x 14.8 in 250 x 250 x 106 x - x 518 x 376 mm |
Shipping Dimensions (L × W × H) |
19.3 x 17.7 x 15 in 490 x 450 x 380 mm |
Approx. Net Weight | 23.2 lb / 10.5 kg |
Approx. Shipping Weight | 28.7 lb / 13 kg |
Indicator Construction | 316 Stainless steel housing, 316 stainless steel bracket |
Indicator Protection | IP68 immersion / IP69K washdown |
Weighing Units | Kilogram, Gram, Pound, Ounce, Pound: Ounce |
Application Modes | Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
Display | 6-digit, 7-segment white LED, 20 mm / 0.8 in high digits |
Check Indicator | 3 color (red, green, orange) 8x16 dot matrix LED |
Keyboard | 6 function keys + 12 numeric capacitive keypad |
Auto-zero Tracking | Off, 0.5 d, 1 d or 3 d |
Zeroing Range | 2% or 100% of capacity |
Interface | RS232 and USB Host included Optional Ethernet, WiFi/Bluetooth, 2nd RS232/ RS485/USB Device, Analog Output, 2 In/4 Out Discrete I/O |
Power | 100-240 VAC / 50/60 Hz Universal Power Supply, hardwired or external power bank |
Battery Life | Depends on the capacity of power bank used (Up to 55 hours with 20,000mAh power bank) |
Calibration | Zero, Span or 3 point-Linear |
